Physical Properties Size
Description | Value | Unit |
|---|---|---|
Size | 340.5 x 226.3 x 100.0 | mm |
Mass
Dscription | Value | Unit |
|---|---|---|
Total mass | 370 | g |
Frame including kill switches | 330 | g |
Corner bracket | 14 | g |
M3 threaded rod | 0.0495 | g/mm |
Highlighted Features
• High degree of freedom for hardware mounting with mounting rings
• Four kill switches • Threaded holes have helicoils and reliability.
• Material: Alu 6061 or 7075 • Total mass of default structure : 326g
• Outside measurements without kill switches: 340.5 x 100.0 x 100.0 mm
Operational temperature: -40°C to +85°C Fits standard PC104
• IPC-A-610 Class 3 PCB and assembly
