RF Communication Board
General
Operating Temperaturet | -40°C to +125°C |
Mass | < 100g |
Voltage | 3.3v, 5v |
Ferquency
UHF | 410.125 ~ 493.125 MHZ |
Transmit
DC Power | 3 - 5.1 W (27-33dBm) |
RF Power | 27 - 33dBm (3dB steps) |
Channel Spacing | 25kHz |
Spurious Responses | < -65dBc |
Frequency Deviation | 3kHz (FM) |
Frequency Stability | ± 2.5ppm |
Receive
DC Power | < 240 mW |
Cell 2-1 | -115dB dBm for 12dB SINAD |
Channel Spacing | 12.5kHz |
Noise Figure | < 2.5dB |
Dynamic Range | -115 to -70dBm |
Frequency Stability | ± 2.5ppm |
